New Diamond DA40 XLT Single Engine Piston Aircraft For Sale

The DA40 XLT boasts a durable & aerodynamically efficient composite airframe & is powered by the bulletproof IO360 Lycoming engine. With a modern all-composite airframe, proven Lycoming IO360 piston engine & the industry leading Garmin G1000NXi, the DA40 XLT combines a blend of modern airframe & avionics with the venerable Lycoming IO360 – arguably the most reliable AVGAS engine of all time.

Type:
Airplane (Single Engine Piston)
Manufacturer:
Diamond
Model:
DA40 XLT
Year:
New
Serial Number:
TBA
Reg. Number:
TBA
Total Time:
Delivery Time Only
Seats:
4
Price:
Price upon request

Filters Sort results
Reset Apply
Price:
Enquire
Aircraft Model & Manufacturer:
Year:
2023
Total Time:
1
Registration Number:
TBA
Serial Number:
TBA
Seats:
Not Listed
Aircraft Location:
Contact Name:
Anita Lentsch
  MESSAGE SELLER

Categories:

Description

Engine
Lycoming IO-360 M1-A AVGAS Piston Engine with 180 HP

Propeller
Hartzell 2-blade metal constant speed propeller or Hartzell 2 blade composite constant speed propeller or MT 3-blade constant speed propeller

Fuel grades
AVGAS / 100LL / 100 / 130LL

Dimensions, Mass & Loading
Length 8.06 m / 26 ft 5 in
Height 1.97 m / 6 ft 6 in
Wingspan 11.63 m / 38 ft 3 in
Seats 4
Empty weight 792 kg / 1,746 lbs
Useful load 408 kg / 900 lbs
Max. take off mass 1,200 kg / 2,646 lbs
Fuel capacity total 189 lt / 136 kg 50 US gal / 301 lbs

Performance (Max. Mass)
Max. cruise speed (MSL, MCP) 263 km/h TAS / 142 kts TAS
Cruise speed at 75% (6,000 ft ISA) 254 km/h TAS / 137 kts TAS
Stall speed, landing configuration 96 km/h IAS / 52 kts IAS
Rate of climb (ISA SL) 4.4 m/s / 880 ft/min
Range at 65% (8,000 ft) 1.426 km 770 nm
Fuel consumption at 65% (6,000 ft ISA) 31 lt/hr / 8.2 US gal/hr
Take-off ground roll (ISA SL) 305 m / 1,000 ft
Landing ground roll (ISA SL) 290 m / 951 ft
Max. operating altitude 5,000 m / 16,400 ft
Max. demonstrated crosswind 37 km/h / 20 kts
