GP 14 E/SE Velo Glider For Sale

The GP 14 E/SE VELO motor glider is the ultimate expression of 13.5 meter FAI racing class – fully flapped & ballasted, combined with everyday usability traits & features.

Type:
Aircraft (Glider)
Manufacturer:
GP Glideres
Model:
GP14 E, SE
Year:
New
Serial Number:
TBA
Reg. Number:
TBA
Total Time:
TBA
Seats:
1
Price:
Price upon request

Filters Sort results
Reset Apply
Price:
Enquire
Aircraft Type:
Aircraft Model & Manufacturer:
Year:
2023
Total Time:
Not Listed
Registration Number:
Not Listed
Serial Number:
Not Listed
Seats:
1
Aircraft Location:
Seller:
Contact Name:
Jerzy Peszke
  MESSAGE SELLER

Categories:

Description

This GP 14 E/SE Velo Glider For Sale has a highly advanced & efficient 30 kW RESLS – Retractable Electric Self-Launching System, developed in partnership with MGM ComproTM & Rotex ElectricTM companies, creates very capable package for both skilled pilots participating in gliding competitions on world-level but also for other users, who prefer cross-country or leisure flying.

The glider comes in two fuselage sizes – REGULAR & SPORT, & two available battery capacities, to improve versatility. It offers absolutely top-shelf performance, matching gliders even of higher classes.

The airframe is designed using the latest 3D tools & methods, modelling & moulding is executed exclusively via CNC machines. Uncompromised aerodynamic concept features sophisticated elliptic shaped wings & horizontal tail-plane, as well as the most efficient & span-variable airfoils.

The production technology is based on the best carbon-epoxy composite materials commercially available, securing unmatched lightweight & strength of the construction. The glider’s structure is also high temperature resistant, which allows to offer a wide range of bespoke exterior graphic schemes & coloured accents.

The safety is enhanced by parachute Ballistic Recovery System (BRS) & crashworthy cockpit with DynafoamTM seat cushioning, all as standard.

The comprehensive option list offers wide spread of items to enable individual customization even for very picky individuals. Highlights of this This GP 14 E/SE Velo Glider For Sale include:

FLIGHT PERFORMANCE DATA (SE)

VNE:      146 kts 270 km/h

L/D:        45 (58 kts)           45 (107 km/h)

G limit:  5,3/-2,65              5,3/-2,65

Wing loading:     7,99-12,29 lb/ft2              39-60 kg/m2

Min. sink speed:               42 kts (7,99 lb/ft2)           78 km/h (39 kg/m2)

Min. sink rate:   1,07 kts (7,99 lb/ft2)       0,55 m/s (39 kg/m2)

Speed at 2,0 m/s (3,89 kts) sink rate:       96-109 kts (7,99-12,29 lb/ft2)     178-201 km/h (39-60 kg/m2)

DIMENSIONS & WEIGHTS

Wingspan:           44,29 ft 13 500 mm

Horizontal stabilizer span:            6,76 ft   2 060 mm

Length: 21,19 ft 6 460 mm

Height: 4,02 ft   1 224 mm

Wing area:          75,35 ft2              7,0 m2

Aspect ratio:       26           26

Empty weight:   452 lb* 205 kg*

Max. take-off weight:    926 lb* 420 kg*

* Approximate weights (dependent on battery size & selected options)PROPULSION SYSTEM

RESLS – Retractable Electric Self-Launching System

Motor power: 30 kW (25 kW continuous)

System voltage: 120V

Removable, dual Gen. 3, “A” traction battery packs integrated in wings with forced air-cooling

Technology: Li-Ion

Usable battery capacity: 5,19 kWh

Operational battery capacity: 4,73 kWh (10% buffer to preserve battery life)

Weight: 31 kg (68 lb)

Motor glider’s self-launch & climb performance on a single charge, equipped with “A” battery pack (TOW: 285 kg [628 lb]):

5 x take-off & climb to 530 m (1 740 ft) altitude

or 1 x take-off & climb to 530 m (1 740 ft) altitude + >100 km (>62 mi) range

or 1 x  take-off & total climb to >2 650 m (>8 700 ft)

Max. climb rate: >5,0 m/s (>9,72 kts)

Ground-roll take-off distance: 160 m (175 yards)

Removable, dual Gen. 3, “B” traction battery packs integrated in wings with forced air-cooling

Technology: Li-Ion

Usable battery capacity: 9,23 kWh

Operational battery capacity: 8,36 kWh (10% buffer to preserve battery life)

Weight: 52 kg (115 lb)

Motor glider’s self-launch & climb performance on a single charge, equipped with “B” battery pack (TOW: 305 kg [672 lb]):

5 x take-off & climb to 850 m (2 790 ft) altitude

or 1 x take-off & climb to 850 m (2 790 ft) altitude + >150 km (>93 mi) range

or 1 x  take-off & total climb to >4 250 m (>13 940 ft)

Max. climb rate: >4,7 m/s (>9,14 kts)

Ground-roll take-off distance: 170 m (186 yards)



Click the “Ask A Question” button to find-out more details about this glider.
